IBM Blutooth Battery Detection
IBM Battery Guardian
Chin-Hong has developed an innovation electric battery management product, which will on sale in 2017.
IBM is Intelligent Battery Manage System.
According the statistics, most of the battery waste and failure were from user’s bad using habits. Such as over charge, over discharge and so on.
Although, nowadays 3C products are become more developed, which makes the car and motorcycle batteries joined a morden generation. Chin-Hong developed IBM Battery Guardian is a whole new electric system of battery management, which can monitor the voltage output and changes by mobile phone APP and computer. To widely use in battery status detection and monitoring; increased the user’s understanding the various different situations of their batteries. Furthermore, it will cultivate the user’s maintenance habits to decrease the waste of batteries, to reach the concept of environment protect.
Although, nowadays 3C products are become more developed, which makes the car and motorcycle batteries joined a morden generation. Chin-Hong developed IBM Battery Guardian is a whole new electric system of battery management, which can monitor the voltage output and changes by mobile phone APP and computer. To widely use in battery status detection and monitoring; increased the user’s understanding the various different situations of their batteries. Furthermore, it will cultivate the user’s maintenance habits to decrease the waste of batteries, to reach the concept of environment protect.
- DC12V can record the name of the batteries.
- Monitoring 4 different batteries
- Setting high and low voltage monitoring
- Alarm of potential difference
- Query the voltage changes by time
- Record the installing time and situations
- Wireless Bluetooth transmission
- Extend multiple PC versions
- Analyze and compare the battery usage
- Monitor/Query the starting and charging status
- Low power consumption
- Prevent the battery failure
Widely apply to any vehicles which using 12V batteries.
Support Android, IOS, PC and MAC systems.
Support Android, IOS, PC and MAC systems.
Body：Length 5.3 x Width1.2 x Height3.7 (cm) , Wire Length 48 (cm), Weight about 0.015 (kg)
Control
Connect the positive/negative connectors to battery terminals (as the following picture)
Download the APP to your mobile phone (IOS interface)
Download the APP to your mobile phone (Android interface)
Turn on the Bluetooth, start the connecting mode
Long press the IBM logo on the top, enter your authorize code
Adding the device, scan immidiately
Setting the battery specification(Default), then press OK.
Display the current battery voltage.
Touch the battery to display the record ot battery voltage usage.
Connect Complete
Car Installation Example
Motorcycle Installation Example
IOS + Android APP
Battery Tester (analizer) BT800
Battery Tester (analizer) BT102
| Model | BT102-機車版 | BT121-汽卡車版 |
|---|---|---|
| Voltage | 12V ( 9V~15V ) | 12V/24V ( 9V ~ 35V ) |
| Battery Tester Function | Yes | Yes |
| Generator Tester Function | Yes | Yes |
| Loading (car starting motor) | Yes | Yes |
| Battery CCA Tester | No: 4 to 20 | 100~1700.CCA |
| Type of Battery | CCA、JIS、EN 、DIN、IEC (Battery type No.) | CCA、JIS、EN 、DIN、IEC (Battery type No.) |
| Battery Plate Tester | Yes | Yes |
| Battery Voltage Tester | Yes | Yes |
| Battery Internal Resistance Tester | Yes | Yes |
| Battery Life | Yes | Yes |
| Battery Connect Un-normal | Yes | Yes |
| Screen Size | 64 x128 LCD | 64 x128 LCD |
| Screen font Size | 4 lines 64 digits | 4 lines 64 digits |
| Size (LxWxH) | 215 x 115 x33mm ±2mm ( without cable ) |
215 x 115 x33mm ±2mm ( without cable ) |
| Weight | 0.47 kg ±0.05kg | 0.47 kg ±0.05kg |
Battery Tester (analizer) BT121
| Model | BT102-機車版 | BT121-汽卡車版 |
|---|---|---|
| Voltage | 12V ( 9V~15V ) | 12V/24V ( 9V ~ 35V ) |
| Battery Tester Function | Yes | Yes |
| Generator Tester Function | Yes | Yes |
| Loading (car starting motor) | Yes | Yes |
| Battery CCA Tester | No: 4 to 20 | 100~1700.CCA |
| Type of Battery | CCA、JIS、EN 、DIN、IEC (Battery type No.) | CCA、JIS、EN 、DIN、IEC (Battery type No.) |
| Battery Plate Tester | Yes | Yes |
| Battery Voltage Tester | Yes | Yes |
| Battery Internal Resistance Tester | Yes | Yes |
| Battery Life | Yes | Yes |
| Battery Connect Un-normal | Yes | Yes |
| Screen Size | 64 x128 LCD | 64 x128 LCD |
| Screen font Size | 4 lines 64 digits | 4 lines 64 digits |
| Size (LxWxH) | 215 x 115 x33mm ±2mm ( without cable ) |
215 x 115 x33mm ±2mm ( without cable ) |
| Weight | 0.47 kg ±0.05kg | 0.47 kg ±0.05kg |
BATTERY Hydrometer
RUBBER BULB SYRINGES
5 Circuits Charge/Discharge Device
